Getting Started with the Yale EN Fire Safe

These safes are ECB-S accredited, the value dependants on individual countries.

These Fire Safes are maximum security and best in class. A detailed breakdown of their security rating is outlined below:

• Complies with European Standard EN14450 S2 for high security.
• Certified to ECB-S according to ISO/IEC 17065.
• High-security lock (EN1300 Class A, VDS Class 2) & reinforced locking bolts on the hinges and door frame.
• Lockout mode activates for 5 minutes after 4 incorrect PIN entries.
• Easy access with resettable master/user codes and external battery compartment.
• Cash rating in UK £4k and valuables £40k (as recognized by the EN11450 S2).
• Fire-resistant up to 972°C.
• Fire tested to NT017.
• 60 minutes fire protection for documents, 30 minutes for digital media (NT017 certified).
• Extra large 22mm diameter locking bolts and hardened steel protection in key areas for added security.

• Open with User Code or separate Mastercode
• Backlit keypad assists opening the safe in poor light
• Shelf included:
  Small and Medium x 1
  Extra large x 2
• External battery, ideal for quick change
• Front end and backend 22mm bolts protecting both sides of the door:
  Small and Medium: 4 active bolts, 3 dead bolts
  Large: 5 active bolts, 4 dead bolts
• Simple LED status indicators
• Locking mechanism: motor
• Keypad locks down for 5 minutes after four incorrect PIN entries
• Supplied with fixings, instructions and 9V battery

This Safe is rated at 1 hour for documents and 30 minutes for data.

• EN Fire Safe
• Batteries 1 x 9V
• Mounting​ Bolts x 2
• Manual x 1

No, these Safes can only be opened with the Mastercode or Usercode.

No, however the brackets can be removed and the shelf can be taken out.

This Safe can only be floor-mounted due to the fire-protective material inside.

Visual instructions to floor mount the Yale EN Fire Safe are included below.
