Troubleshooting your Yale Smart Indoor Camera

1. Check Wi-Fi Compatibility and Signal Strength

Important: Yale Smart Cameras only support 2.4 GHz Wi-Fi networks. They are not compatible with 5 GHz networks.

Steps to Troubleshoot:

• Verify your router’s frequency:
  Ensure your router is broadcasting a 2.4 GHz signal. If you're using a dual-band router (2.4 GHz + 5 GHz), setup issues may occur if both bands share the same network name (SSID).
• Split your Wi-Fi bands:
  Rename the 2.4 GHz and 5 GHz networks with unique SSIDs (e.g., Home_2.4 and Home_5). Then, connect your phone to the 2.4 GHz network and retry the camera setup.
• Confirm your internet connection is active:
  A router may still broadcast a network even if the internet is down. Test by opening a website in your browser.
• Check signal strength at the device location:
  Use a free speed test app to measure Wi-Fi quality where the device is installed. If the signal is weak, try moving the device closer to the router during setup.

2. Grant App Permissions

Connection issues may occur if the Yale Home app does not have the necessary permissions.

To ensure successful set up:

• Accept all permission prompts during app installation and device setup.
• Required permissions typically include:
  • Bluetooth – for device discovery
  • Location access – for Wi-Fi setup and connectivity

If these permissions are denied, the app may not be able to detect or connect to your Yale device.

3. Ensure the Camera is Connected to Mains Power

The Indoor Camera does not have an in-built battery, therefore without mains power- you will not be able to set it up.

4. Special Characters in Wi-Fi Network Name (SSID)

Yale cameras running earlier firmware versions may fail to connect during setup if your Wi-Fi SSID (network name) or password contains special characters (e.g., commas, exclamation marks, symbols).

To successfully set up your camera and update its firmware, follow these steps:

Option 1: Temporarily Change Your Router’s SSID

1. Log in to your router settings and change the SSID (network name) to something simple—avoid special characters.
2. Connect and onboard the Yale camera to this simplified network.
3. Allow the camera to complete its firmware update.
4. Factory reset the camera.
5. Revert your router’s SSID back to the original name (with special characters, if desired).
6. Re-onboard the camera to your original network.

Option 2: Use an Alternative Network (e.g., Mobile Hotspot)

1. Create a mobile hotspot on your phone with a simple SSID (no special characters).
2. Onboard the camera to this hotspot.
3. Wait for the firmware update to complete.
4. Factory reset the camera.
5. Connect the camera to your regular Wi-Fi network.

5. Camera Not Broadcasting Its SSID

When setting up your camera, make sure it is in onboarding mode—this is indicated by a flashing green light.

In this mode, the camera should broadcast its SSID. You can check this by opening your phone’s Wi-Fi settings and looking for the camera in the list of available networks.

Once you find the camera’s SSID, confirm that the serial number in the SSID matches the one printed on the product label.

If the serial numbers do not match, or you are unable to see the cameras SSID in the available network list, please contact Yale Customer Support for assistance.

6. Hardware Failure

If you've followed all the previous steps and still can't set up your camera, we recommend performing a hardware reset.

You can find step-by-step reset instructions in the Support Centre within your Yale Home app.

If set up still fails after a successful reset, please reach out to Yale Customer Support for further assistance.

1. Move the Camera Closer to the Router or Access Point

To ensure a strong and stable Wi-Fi connection, position your device as close as possible to your router or the nearest mesh node.

Reconnecting to the Optimal Access Point After Mounting

If you initially set up your device near one Access Point (AP) but later mount it in a different location with a closer AP, the device may still connect to the original AP. This can affect performance unless the device is reset.

To ensure your device connects to the strongest available Wi-Fi signal:

1. Locate the reboot button on the device.
2. Press and hold the reboot button for a second.
3. The camera and its Wi-Fi module will restart.
4. During the reboot, the device will scan for available Access Points and automatically connect to the one with the strongest signal (RSSI).

Note: If your camera is running firmware version v1.5.23 or later, you can restart it remotely using the Yale Home app (if the camera is online). This also triggers a re-scan for the strongest available Access Point.

This step is especially important in mesh or multi-AP environments to ensure optimal performance.

2. Check Your Yale Camera’s Current Wi-Fi Signal Strength

To check your Yale camera’s current Wi-Fi signal strength, follow these steps in the Yale Home App:

1. Open the Yale Home App and select your camera.
2. Tap on Settings.
3. Go to Utilities.
4. Select Wi-Fi Connection.

Once you're there, look for the RSSI (Received Signal Strength Indicator) value. Here's how to interpret it:

• Good Signal: ~ -40 to -55 dBm
• Poor Signal: ~ -65 dBm or lower

If your signal is poor, you might consider:

• Moving your router closer to the camera.
• Reducing physical obstructions (like walls or metal objects).
• Using a Wi-Fi extender or mesh system.

3. Reconnect Your Camera to a Closer Wi-Fi Access Point

If you've moved your camera after the initial setup, follow these steps to reconnect it to the strongest available Wi-Fi signal:

• Reboot the Camera
  Press and hold the reboot button for a second.
• Wait for Reboot
  The camera will automatically restart and connect to the strongest available Wi-Fi network.
• Check Signal Strength
  Once the camera has rebooted, open the Yale Home app and check the camera’s signal strength under the device settings.

4. Try Fully Reinstalling The Camera

To reset your Yale Indoor Camera, please follow the process below.

• Open the Yale Home app.
• Select your camera and then the settings icon.
• Scroll down to Utilities and select Remove Device.

Once the camera is removed, you will also need to manually reset the camera.

• Press and hold the button on the rear of the camera until you hear a beep (at least 12 seconds).

• Release the button, you will see a sequence of green and red LED flashes.
• Wait 60 seconds for the camera to fully reboot. The camera is now removed from your app and reset.

Once this has been completed, please select the top right "+" option from your Yale Home app dashboard, to setup the camera again.

You can reset your password in the app by choosing the Forgot Password function from the login screen, or alternatively via the online account management portal link here

You can reboot the device in two ways:

• Via the Yale Home App
• Directly on the Camera

1: Reboot via the Yale Home App

1. Open the Yale Home app.
2. From the dashboard, tap on your Camera.
3. Tap the Settings icon in the top right corner.
4. Scroll down to Utilities and select Restart Device.
5. Allow 60 seconds for the camera to fully reboot.

2: Reboot via the Camera

1. Press and hold the reboot button for a second.
2. Allow 60 seconds for the Camera to fully reboot.

A hardware reset restores your Yale Smart Indoor Camera to factory settings. This process:

• Removes: Wi-Fi network settings and internally stored video clips.
• Retains: Registration to the current user’s Yale Home account and cloud-stored data.

Important: A hardware reset does not remove the device from your Yale Home account. Video clips stored in the cloud and the device’s registration remain intact. Removal from a Yale Home account is covered in Step 2.

Step 1: To Perform a Hardware Reset:

1. Press and hold the button on the rear of the camera until you hear a beep (at least 12 seconds).
2. Release the button, you will see a sequence of green and red LED flashes.
3. Wait 60 seconds for the camera to fully reboot. The camera is now removed from your app and reset.

Important: After a reset, the camera can only be set up again if it’s removed from the original owner’s account - as per the next steps below. This prevents stolen devices from being re-registered.

Step 2: To Remove the Camera from Your Yale Home Account:

1. Open the Yale Home app.
2. From the dashboard, tap on your Camera.
3. Tap the Settings icon (top right corner).
4. Scroll down to Utilities and select Remove Device.
5. Follow the on-screen prompts.

Final Notes:

• Resetting is useful when changing Wi-Fi networks or preparing the device for a new location.
• Always ensure the device is removed from your account before transferring ownership.
