Yale

8200 Series

StandardANSI / BHMA A156.5.2001
Testing cyclesTested up to 100,000 cycles
Material
- ChassisSteel
- Latch & BoltZinc
- Cylinder HousingSteel
- Round PlateBrass
Backset60mm / 70mm
Door Thickness35~50mm
FunctionResidential application
Anti - Sawing InsertHardened Steel
CylinderSolid brass 5-pin tumbler cylinder
No. of Keys3pcs of nickel plated btass key
FinishesUS3 - Polished Brass
US4 - Satin Brass
US5 - Antique Brass
US32 - Polished Stainless Steel
US32D - Satin Stainless Steel

  • Standard:
    Testing cycles:
    Material:
         Chassis:
          Latch & Bolt:
          Cylinder Housing:
          Round Plate:
    Backset:
    Door Thickness:
    Function:
    Anti - Sawing Insert:
    Cylinder:
    No. of Keys:
    Finishes:

    ANSI / BHMA A156.5.2001
    Tested up to 100,000 cycles

    Steel
    Zinc
    Steel
    Brass
    60mm / 70mm
    35~50mm
    Residential application
    Hardened Steel
    Solid brass 5-pin tumbler cylinder
    3pcs of nickel plated brass key
    US3 - Polished Brass
    US4 - Satin Brass
    US5 - Antique Brass
    US32 - Polished Stainless Steel
    US32D - Satin Stainless Steel
