YMF30+

Big beams with Quality
RFID Smart Lock

It’s natural for a home to have multiple guests coming together under the same roof. Hence, the YMF30+ smart lock lets you enter home without needing to remember PIN codes simply because you can use RFID key tags for easy door access. You can even issue single-use temporary passwords for your visitors and set schedules to let them in while you’re away. The voice guide feature that comes with YMF30+ is there to walk you through the step-by-step process on various operations possible on your smart lock, including PIN code scrambling to make your code harder to follow.

Shop YMF30+ now

Type	Mortise lock
Fingerprint	None
Card	40 RFID Cards
Mechanical key	2
PIN code	4 - 10 digits
Color	Black
Thickness	40-80mm
Backset	60mm
Front body dimension	66 (W) x 320 (H) x 25 (D) mm
Back body dimension	66 (W) x 320 (H) x 31 (D) mm
Door Type	Wood
Handling	Reversible (Left or Right)

YMF30+ APAC_MANUAL_180308(out)_ISL-1628-06(PDF, 13 MB)

Access your lock using your phone

With Yale link, you can easily unlock your Yale digital door lock with your smartphone. No need to remember password, no need to carry cards and keys anymore. Hassle-free life is awaiting you!

Key Features

Live smart with our home smart lock systems by upgrading your home security system to the all-new Yale Smart Lock. Now you can live smartly by unlocking your door with your fingerprint, RFID key tag, or a pin code.

Yale Link Compatible
Yale Link App lets you access and unlock the smart lock with your smartphone.
Yale Link App is an optional feature for mobile access and remote access.
RFID Card Access
Access using your registered RFID cards. Once you lose a card key, it has no validation as long as you re-register rest of your card keys.
Fake PIN Code
To prevent the PIN Code from being exposed, it allows you to enter fake numbers before or after entering your actual PIN Code.
Alarm (Break-in / Damage)
80dB alarm will be triggered if anyone attempts to damage the lock, force the door open.
Automatic Locking
After the door was closed, Yale smart locks automatically locks after 3 seconds. (Manual operation is also available.)
Low battery alarm and emergency power supply terminal
It warns in case of low battery. And when the batteries are completely discharged, you can easily supply emergency power to the lock with a standard 9V battery.
