YDM3109A

Mortise Smart Lock

Main Feature:

Pin Code
RFID Key Tag
Bluetooth
Mechanical Key Override
Yale Home App

1 of 3

Model: YDM3109A
Color: Silver
Locking Type: Mortise Lock
Backset: 60mm / 70mm
Glass Door Thickness: 35 - 100mm
Battery: Alkaline (AA x 4)

Product Dimension:

Size (Front): 68.6(W) x 306.6(H) x 27(D) mm
Size (Back): 72.8(W) x 306.6(H) x 37(D) mm

Access Credential:

Fingerprints: No
PIN Code: Available
RFID Key Tag: No
Mechanical Key Override: Available
Bluetooth: Available
WiFi Connection: Available
Remote Control: Available (Optional - Sold Separately)

Maximum No. of Users:

Fingerprints: No
PIN Code: Up to 100 Users
RFID Key Tag: No
Mechanical Key Override: 2 Keys
One Time Code: 1 Only

Additional Features:

Always in the know
The activity feed in Yale Access App tracks how and when your door is locked and unlocked.

Control who has access
Let visitors in and out when you are not at home.

Keep your home secure
Check if your door is locked from anywhere.

Monitor access from anywhere
Always know who is coming and when.

Voice Guide
Automatic Locking
Alarm (break-in / damage)
Anti-panic Egress
Fake PIN Code
Low Battery and Emergency Power
Remote Control (Optional)
