Getting Started with Yale Linus® Smart Lock L2 Lite

This question has its own page. Click here to read full answer.

There are a few different options for installing the Yale Linus L2^® Lite Smart Lock, as below:

• If you have a Euro profile/DIN cylinder lock, you may well be able to install the Linus lock over your existing cylinder. To double-check this, please go to our compatibility checker.
• If you find you need a replacement cylinder, we have a fully adjustable cylinder specifically for the Linus Smart Lock range. Please find more information here.

Although we try to be compatible with as many locks as possible, if you have a Euro profile/DIN cylinder there is a chance that you may need to change the cylinder. You can check this using our compatibility checker.

If you find you need a replacement cylinder we have a fully adjustable cylinder specifically for your Linus L2 Lite Smart Lock. Please find more information here.

Dimensions: 62mm Diameter x 72mm Height

Weight: 260g (without batteries)

The Yale Linus^® Smart Lock L2 Lite is designed to offer hassle-free installation. There is no drilling or damage to the door and with the step-by-step instructions provided, installation is quick and simple.

Our step-by-step DIY guides makes installation quick and effortless, with helpful tips and visuals to guide you along the way: Click Here

No, the Linus^® Smart Lock L2 Lite is powered by the 3 x CR123A batteries supplied in the box.

This question has its own page. Click here to read full answer.

The Yale Linus^® Smart Lock L2 Lite offers simple, secure control through the Yale Home app when you’re within Bluetooth range.

For broader smart home integration, L2 Lite supports Matter over Thread, enabling compatibility with a wide range of popular devices and platforms. This means you can manage your lock locally or remotely via your preferred smart home system.

Because L2 Lite doesn’t include built-in Wi-Fi, connecting to third-party devices that don’t support Matter over Thread requires the Yale Connect Wi-Fi Bridge (sold separately). The bridge also unlocks full remote access through the Yale Home app, so you can control your lock from anywhere.

​1 x Yale Linus^® Smart Lock L2 Lite​

1 x Mounting plate​

1 x Mounting plate adhesive tape

1 x 2.5mm hex key​

3 x CR123A Batteries

Available in Silver or Black

Yale Home is the application to use on your Smartphone. The app is available on the Apple App Store or Google Play.

Download the Yale Home App from the links below.

Once you have downloaded the Yale Home app you will need to click on 'Create an account' or 'Sign in' if you already have an account.

To remove the battery cover:

1. Press down on the side button to release the holding clip.
2. While holding the button, pull the cover back to remove it.

To reattach the battery cover:

1. Slide the cover back into place, ensuring it is aligned with the clip.
2. Push gently until you hear a click, confirming it is securely attached.

The Linus^® Smart Lock L2 Lite will automatically power on when the batteries are inserted. Once the last battery is connected, a white LED will pulse around the KeySense button along with a power up chime sound.

Please note: When the lock has been calibrated, removing and reinserting batteries will start an automatic calibration process, ensuring the L2 Lite is fully locked.

To locate the QR code to setup the Yale Linus^® Smart Lock L2 Lite on your Yale Home app, please follow the steps below.

1. Firstly, remove the locks battery cover. Press down on the side button to release the holding clip.
2. While holding the button, pull the cover back to remove it.
3. The QR code is located beneath, on the front of the lock.

The KeySense feature on the Linus^® Smart Lock L2 Lite is activated by a physical button located at the center of the device. Pressing this button allows you to control the lock without using the app.

KeySense supports two main functions:

Lock and Unlock Immediately

• Quick press the button to immediately lock or unlock the door.

Lock After Delay

• Press and hold the button to activate a delayed locking sequence (the delay period is configured within your Yale Home app).
• This is useful when leaving your home—after holding the button, you’ll hear a sound notification, and the lock will automatically engage after a short countdown.
