H Series

Specifications

• Heavy duty sashlock with 72mm centres
• Backset 55mm with option of 60mm on request
• Follower 8x8mm
• Through fixing holes with 38mm centres
• AISI 304 stainless steel front and strike plate
• Square front and strike plate with option for radius type on request
• Stainless steel latch and deadbolt
• 20mm double throw deadbolt
• Grade 8
• Door mass up to 200kg at max. closing force of 15N

Features

• Tested to EN12209:2003 - suitable for public doors
• CE certified - suitable for steel fire doors upto 200kg, 240 minutes for metal doors and 120 munites for timber doors
• Latch operated by handle or cylinder
• Satin stainless steel finish
• Reversible for left or right hand door

Specifications

• Heavy duty deadlock
• Backset 55mm with option of 60mm on request
• Stainless steel 304 front and strike plate
• Square front and strike plate with option for radius type on request
• Stainless steel deadbolt
• 20mm double throw deadbolt
• Grade 8
• Door mass upto 200kg at max. closing speed of 15N
• 200,000 cycles tested

Features:

• Tested to EN 12209:2003 - suitable for public doors
• CE certified - suitable for steel fire doors upto 200kg, 240 minutes for metal doors and 120 minutes for timber doors
• Satin stainless steel finish
• Reversible for left or right hand door

Specifications

• Heavy duty mortice latch
• Backset 55mm with option of 60mm on request
• Follower 8x8mm
• Through fixing holes with 38mm centres
• Stainless steel 304 front and strike plate
• Square front and strike plate with option of radius type on request
• Stainless steel 304  latch
• Grade 8
• Door mass up to 200kg at max. closing force of 15N
• 200,000 cycles tested

Features

• Tested to EN 12209:2003 - suitable for public doors
• CE certified - suitable for steel fire doors 4 hours fire resistance
• Latch operated by handle only
• Satin stainless steel finish
• Reversible for left or right hand doors

Specifications

• Heavy duty nightlatch with 72mm centres
• Backset 55mm with option of 60mm on request
• Follower 8x8mm
• Through fixing holes with 38mm centres
• Stainless steel 304 front and strike plate
• Square front and strike plate with option of radius type on request
• Stainless steel 304 latch
• Grade 8
• Door mass up to 200kg at max. closing force of 15N

Features

• Tested to EN 12209:2003 - suitable for public doors
• CE certified - suitable for fire doors
• Latch operated by handle or cylinder
• Satin stainless steel finish
• Reversible for left or right hand doors

Specifications

• Heavy duty bathroom lock with 78mm centres
• Backset 55mm with option of 60mm on request
• Follower for latch and deadbolt 8x8mm
• Through fixing holes with 38mm centres
• Stainless steel 304 front and strike plate
• Square front and strike plate with option for radius type on request
• Stainless steel latch and deadbolt
• 20mm single throw deadbolt
• Grade 8
• Door mass upto 200kg at max. closing force of 15N
• 200,000 cycles tested

Features

• Latch operated by handle
• Deadbolt operated by privacy set with 8x8mm spindle
• Satin stainless steel finish
• Reversible for left or right hand door
