Knob locks

Specifications

• Stainless steel or brass knobs, 75mm diameter rose
• No exposed mounting screw
• 6 pins cylinder, brass plug and brass housing (3 keys)
• Standard backset, fixed latch 60mm or 70mm available, latch bolt is stainless steel construction, it is UL fire latch
• Suitable for door 35~45mm thickness
• Stainless steel knob with SS faceplace and strike, other finish knob with brass faceplace and strike.

Features

• Conforms to ANSI Grade 2 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), PSS-Polished Stainless Steel(US32)

Specifications

• Stainless steel or brass knobs, 75mm diameter rose
• No exposed mounting screw
• 6 pins cylinder, brass plug and brass housing (3 keys)
• Standard backset, fixed latch 60mm or 70mm available, latch bolt is stainless steel construction, it is UL fire latch
• Suitable for door 35~45mm thickness
• Stainless steel knob with SS faceplace and strike, other finish knob with brass faceplace and strike.

Features

• Conforms to ANSI Grade 2 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), PSS-Polished Stainless Steel(US32)

Specifications

• Stainless steel or brass knobs
• 65mm diameter rose
• 5 pins cylinder, brass plug and zinc alloy housing (3 keys)
• Entrance knobset, storeroom knobset and passage knobset with adjustable latch
• Privacy function knobset wtih fixed latch, 60mm backset or 70 mm backdset on request
• Suitable for door 35~45mm thickness
• Square faceplace and strike in 304 stainless Steel material
• Zinc alloy latch bolt

Features

• Conforms to ANSI Grade 3 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), SP-Polished Stainless Steel(US32)

Specifications

• Stainless steel or brass knobs
• 65mm diameter rose
• 5 pins cylinder, brass plug and zinc alloy housing (3 keys)
• Entrance knobset, storeroom knobset and passage knobset with adjustable latch
• Privacy function knobset wtih fixed latch, 60mm backset or 70 mm backdset on request
• Suitable for door 35~45mm thickness
• Square faceplace and strike in 304 stainless Steel material
• Zinc alloy latch bolt

Features

• Conforms to ANSI Grade 3 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), SP-Polished Stainless Steel(US32)

Specifications

• Stainless steel or brass knobs
• 65mm diameter rose
• 5 pins cylinder, brass plug and zinc alloy housing (3 keys)
• Entrance knobset, storeroom knobset and passage knobset with adjustable latch
• Privacy function knobset wtih fixed latch, 60mm backset or 70 mm backdset on request
• Suitable for door 35~45mm thickness
• Square faceplace and strike in 304 stainless Steel material
• Zinc alloy latch bolt

Features

• Conforms to ANSI Grade 3 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), SP-Polished Stainless Steel(US32)

Specifications

• Stainless steel or brass knobs
• 75mm diameter rose
• 5 pins cylinder, brass plug and zinc alloy housing (3 keys)
• Entrance knobset and passage knobset with adjustable latch
• Privacy function knobset wtih fixed latch, 60mm backset or 70 mm backdset on request
• Suitable for door 35~45mm thickness
• Square faceplace and strike in 304 stainless Steel material
• Zinc alloy latch bolt

Features

• Conforms to ANSI Grade 3 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), SP-Polished Stainless Steel(US32)

Specifications

• Stainless steel or brass knobs
• 75mm diameter rose
• 5 pins cylinder, brass plug and zinc alloy housing (3 keys)
• Entrance knobset and passage knobset with adjustable latch
• Privacy function knobset wtih fixed latch, 60mm backset or 70 mm backdset on request
• Suitable for door 35~45mm thickness
• Square faceplace and strike in 304 stainless Steel material
• Zinc alloy latch bolt

Features

• Conforms to ANSI Grade 3 requirements

SS-Satin Stainless Steel(US32D), PB-Polished Brass(US3), AB-Antique Brassl(US5), AC-Antique Copper(US11), DC-Satin Nickel(US15), SP-Polished Stainless Steel(US32)

Specifications:

• Stainless steel or brass
• Brass cylinder and keys (3 keys)
• Adjustable bolt 60-70mm backset
• Suitable for door 35-45mm thick

Features:

• Key and turn operation or key operation from both side
• Reversible for left or right hand doors
