Smart Living Range

Innovative digital door viewer - Very easy to fit

Specifications:

• 3.2" LCD screen
• 0.3 MP camera with 105 degree viewing angle
• Fits standard 14mm hole from mechanical door viewer
• Door thickness 38-110mm
• Size 128 x 68 x 15mm
• 2 pcs. AAA batteries

Features:

• Very clear image on screen
• Easy operation - just press the button
• Automatic switch off after 10 seconds
• Very easy to install
• Can replace mechanical door viewer without additional work

YDR3110 rim lock is a smart solution for residential & light commercial applications. 2 access solutions to open your door: RF Card key & PIN code. The innovative features, such as alarms, fake code or automatic locking will provide comfort and will increase your feeling of security.

Specifications:

• Type: rim lock
• Credentials:
• Pin code (4 to 12 digits)
• RF Card key: 4 (up to 20 users)
• Backset: 60-90mm
• Colour: black
• Door thickness: 35-45mm
• Dimensions: front body 19(D)x 65 (W)x160(H); Back body 36(D)x158 (W)x 85(H) mm
• Integration: available upon request-RF link
• Options: extra remote controls & card keys
• Suitable for left or right opening

Features:

• Various access (PIN code & RF Card key)
• Smart touchpad
• Operation status notification
• Missing key invalidation
• Automatic locking
• Alarm (break-in/damage)
• Low battery alarm & emergency power with 9v battery

YDM3168 is a digital door lock, suitable for steel and wooden doors (40 to 105mm). Its a 3 deadbolts motorized lock featuring 2 access options: RF card key & PIN code. Other features include alarm, fake code, automatic locking and integration.

Features

• PIN code: 6-12 digits
• Proximity cards up to 40 users
• Zigbee and Zwave integration module available (optional)
• Mechanical keys override
• Voice guidance available
• Built-in 80db burglar alarm
• Easy installation
• Scramble code
• Available in silver finish
• Smart touchpad
• Anti-panic egress with safe handle
• Fake PIN Code
• Automatic locking
• Low battery alarm
• Emergency power with 9V battery
• Remote control (optional)

Specifications

• Motorized mortice lock
• Backset: 60mm
• Door Thickness: 40 to 105mm
• 4 x AA batteries
• Available for wooden and steel doors
• Automatic lock mode
• Operation temperature: -15 to +55C
• Suitable for left or right opening
• Dimensions: front body 311 (D) x 64 (W) x 26 (H) mm; back body 311 (D) x 72(W) x 31 (H)mm
• Compatiable for both Left and Right side door opening.

YDME70 is a mortice digital door lock with multiple modes of access ideal for wooden or metal doors.ideal for wooden or metal doors.

Features

• Touchscreen keypad
• 6 digits user pin code and master pin code
• Ways to unlock:
  - PIN code
  - RF card
  - Mechanical key
• Electronic lock
• English voice guide
• Fake PIN code
• Break-in and damage alarm
• Low battery indicator & emergency power with 9v battery
• Anti-panic egress with safe handle

Specifications

• Mortice: five latch
• Door thickness: 35-55 mm
• Credentials:
  - PIN code (up to 32 PIN codes)
  - RF card (up to 32 RF cards)
• Keys 3pcs.
• MF1 cards 4pcs.
• 8 pcs. batteries

YDME50 is a digital lock for internal and external wooden and metal doors.

Features

• Touchscreen keypad
• 6 digits user PIN code and master pin code
• Ways to unlock:
  - PIN code
  - RF card
  - Mechanical key
• Low battery indicator & emergency power with 9v battery
• Anti-panic egress with safe handle

Specifications

• Mortice: single latch
• Door thickness: 35 - 55 mm
• Credentials:
  - PIN code (up to 78 PIN codes)
  - RF card (up to 30 RF Cards)
• 3pcs keys
• 4pcs MF1 cards
• 4pcs batteries

ENTR^™ is a smart lock solution that allows you to control your door lock from your smartphone, tablet and other Bluetooth enabled devices.

Features

• Provides users with mobile connectivity - meaning they can control and monitor the ENTR^® lock from their smartphone or any other Bluetooth device
• Ideal for any door type or size with euro profile cylinder. Internal cylinder dimension: minimum 35 mm up to 78 mm (gaps of 5 mm)
• Automatic locking - shut the door and it will automatically lock
• Secure, encrypted wireless communication between system elements
• Wire-free and wireless - ENTR^™ is a battery-operated system
• Wired charger included in the kit (for the European 2 pin plug please order the product replacing the last 2 digits of the kit part number with the digits: 1S)
• Receive notifications - locked / unlocked door and battery power level
• Create virtual keys
• Program scheduled access authorizations with your fingerprint

Specifications

• Automatic locking

• Easy to install - no drilling or wiring

• Front body measures 150 mm x 55 mm x 54 mm

• Operating temperature -10°C ~ +50°C

• IP44 weather resistant - do not splash water on the device

• Communication frequency between door unit and credentials: 2.4 GHz

• Battery type & power: rechargeable Lithium-ion, 7.4V 2600mAh

• Bluetooth Smart Technology between ENTR^® lock and smartphone: Bluetooth 4.0

• Transforms any door into a smart one with a simple and affordable cylinder retrofit solution

• Mechanical key override - backup solution

• ENTR^® consumes 300% less energy than common wired locks

• LED indications:

  - Low battery
  - Fault during lock/unlock operation
  - Mute
  - Door opened/closed
  - Auto/manual locking mode

Smart locks make your life easier and put you in control, wherever you are. Lock and unlock your door from anywhere in the world. Forgot to lock the door when you left for that business trip this morning? Our Assure^® Smart Lock will alert you when your door is open or unlocked.

Highlights

• Simple Installation - Replaces your existing deadbolt in minutes with just a screwdriver.
• Touchscreen Keypad - Wakes with a touch and has backlit numbers that won't wear off.
• One-touch Locking - Lock up without the hassle of keys by tapping the kaypad with 3 fingers.
• Manage Access - Create and share up to 25 (250 with Network Module) unique pin codes.

Features

• App control
• Door SenseTM - Be sure it is closed
• Auto locking and unlocking when you're
  nearby
• Guest access
• Activity monitoring
• Integration with global partners
• Remote functionalities
• Easy installation
• Compatibility: fits a wide range of doors

Specifications

• Key-free
• Motorised deadbolt
• Backlit keypad
• Battery back-up
• Voice assistance
• Weather protected
• BLE Enabled
• Connected (TBC)
• Auto lock/unlock
• BHMA Grade 2 Certified Deadbolt
• Step by step installation guide on BILT App

Network Module - For voice assistant functionality and remote access.

• Monitor access remotely - Always know who is coming
• Control who has access - Let visitors in and out when you are not home
• BLE - Establishes a secure channel and uses encryption when sending sensitive information
• Keep your home secure - Check if your door is locked from anywhere

Connect Bridge - For voice assistant functionality and remote access

• Keep your home secure - Check if your door is locked from anywhere
• Monitor access remotely - Always know who is coming
• Control who has access - Let visitors in and out when you are not home

The Yale Access App

• App control - lock and unlock your door from your app, anywhere in the world.
• DoorSense^™ Technology - the lock will check the status of the door and tell you if your door is securely closed and locked. (no other lock in the market has this)
• Activity monitoring - track activity and always know who is coming and going at your doorstep with a 24/7 feed.
• Guest Access - grant unlimited digital keys valid for a few weeks, a few hours, or a few minutes. Never worry about lost or stolen keys again. (app access cannot be copied like a key)

Yale code handle is an innovative solution with an automatic locking mechanism built into the handle, which only allows the door to be opened when entering the correct personal code.

Features

• Auto locking function available
• Master code and up to nine different user codes
• Visual and acoustic feedback
• Easy to fit, no cables
• Indoor use only

Specifications

• Locking mechanism is operated with 4 buttons
• Unique reset functions
• Master code and user codes can be reset as and when required
• Two CR2, 3V lithium batteries in outer handle
• Stainless steel and zinc chrome finish

Our reliable and secure Cabinet Lock provides convenience while offering optimum safety.

Features

• Two levels of key management (master, user)
• Supports Mifare Classic, Ultralight, DESfire EV1 Supports public mode or assigned mode
• Auto-locking or self-locking
• Intrusion alarm
• Supports external power through 5V Micro USB

Specifications

• Size: Lock Body: 66(W) × 122(H) × 27.7(T)mm
  Front: 34.2(W) × 109.3(H) × 9(T)mm
• Door Thickness: 10 ~ 30mm
• Power: Battery Type: Three AA battery
• Material: PC / ABS Alloy

The Yale Smart Home CCTV Kit gives you the peace of mind that your home is securely protected by allowing you to check in when you're out. View your home from anywhere at any time via a smartphone, with the cameras providing enhanced night vision for clear images, even in poor weather conditions.

Features

• Smartphone Notification: Receive alert notifications if an event is detected

• In-App Control: Control from your smartphone

• Intelligent Detection: Triggers recording when event is detected

• 4M High Definition Quality: Crisp detailed footage

• Intelligent Search: Highlights within the timeline allowing you to pinpoint specific activity

• Easy Installation: Easy to install with quick set-up wizard in the app

• Control via your Smartphone: Keep an eye on your property whilst you're away by viewing a live feed of your property via your smartphone or tablet.

• Remote Viewing: View images of your home anytime anywhere via your Smartphone or Tablet.

• Protect what matters: With the ability to view recorded footage directly in your Yale View App, you can now keep an eye on what matters most with ease.

The Yale Smart Home Security Ecosystem

Centring around the Yale Smart Home Hub*, all app enabled products in the Yale Smart Living range can work together as part of a connected Smart Home security system. By combining our smart door locks, CCTV, IP cameras and home alarms, you can build a Yale Ecosystem to suit your home, integrated under one seamless, single-point-of-access - the Yale Home App.

The Yale Smart Home CCTV Range gives you the peace of mind that your home is securely protected by allowing you to check in when you're out. Live viewing with full HD 1080 for detailed footage, motion detection and enhanced night vision for clear images, even in poor weather conditions, all accessible through the Yale View App, It's everything you need to protect what matters. The Smart Home CCTV range provides you with intelligent search allowing you to search back on what's been happening at home so you never miss a moment.

Features

• In-app control
• Live viewing
• Motion detection

Extended Features

• Intelligent Search and Detection: Intelligent search allows you to search back on your recorded timeline and detection triggers recording when an event is detected.
• Customisable Detection Area (Image masking): Control which areas are covered and which are ignored.
• Expandable: Expand your system with up to 2 additional wired cameras and 2 WiFi cameras.
• 20m Night Vision: 20m night vision activates automatically in the dark, giving you full visibility around the clock.
• 1TB storage: Records footage for later viewing.
• Full HD 1080 resolution: For crisp detailed footage.
• Weatherproof: Ready for the elements come rain or shine.
• Easy installation: Easy to install with quick set-up wizard in the app.
